CONTEC CMS1000 Touch Screen Patient Monitor Human/Veterinary Portable 6 Parameter

CONTEC CMS1000 Touch Screen Patient Monitor Human/Veterinary Portable 6 Parameter Human Use patient Monitor CMS1000 Accessories 1)Adult fingertip SpO2 probe 1)Adult NIBP cuff 2)NIBP extension tube 2)ECG lead cable 3)ECG electrode 4)TEMP probe 3)Power cord 4)User Manual Veterinary Patient Monitor CMS1000VET Accessories 1)SpO2 probe extension cable 2)Vet fingertip SpO2 probe 3) Vet NIBP cuff 4)NIBP extension tube 5)ECG lead cable 6)ECG electrode 7)Temperature probe 8)Power cord 9)User Manual Introduction The monitor has abundant functions, which can be used for monitoring of adult, pediatric and neonate. It is powered by 100 V-240 V ～ 50 Hz/60 Hz. Users may select different parameter configurations according to requirements. It displays real-time data and waveform by 5'' color TFT LCD. It can be connected to Central Monitoring System via wireless network to form a network monitoring system. It can monitor such parameters as ECG, RESP, SpO2, PR, NIBP, TEMP and CO2 (optional). It integrates parameter measurement module and display into one device to form a compact and portable monitor. Function Parameters: ECG, RESP, SpO2, PR, NIBP, TEMP, CO2 (optional) 1)ECGHeart rate (HR) ECG waveform 2)RESPRespiration rate (RR) Respiration waveform 3)SpO2Oxygen saturation (SpO2) Plethysmogram (PLETH) waveform Pulse rate (PR) Bar graph 4)NIBPSystolic pressure (SYS), Diastolic pressure (DIA), Mean pressure (MEAN) 5)TEMP 6)CO2 (optional) EtCO2, INSCO2, AWRR It has abundant functions, such as audible and visual alarm, trend data storage and output, NIBP measurement, alarm event marking and drug concentration calculation. Features 1)5'' color TFT LCD, multi-language interface (simplified Chinese, English, Russian, Kazakh, Slovak, Czech, Spanish, etc.). 2)Fanless design, quiet, energy-saving and clean, which reduces the possibility of cross-infection. 3)With standard interface, OxyCRG, big character interface and full-lead interface, convenient to observe. 4)Waveform, parameter color and location can be set optionally. 5)All operations can be completed by the buttons and touch screen. 6)Adopt digital SpO2 technology, anti-motion and anti-ambient light interference, and measurement can be performed under the circumstance of low perfusion. 7)NIBP measurement mode: Manual / AUTO / STAT, storage for 2400-group NIBP data. 8)Connect to Central Monitoring System by WiFi. 9)Built-in large-capacity battery, meets the requirements of long-term operation. AC/DC, achieves uninterrupted monitoring. 10)Anti-high frequency surgical unit, defibrillation-proof (special leads are necessary). Performance ▲ECG Lead mode: 3-lead: I, II, III 5-lead: I, II, III, aVR, aVL, aVF, V Waveform: 3-lead, 1 channel 5-lead, 2-channel Gain: 2.5 mm/mV, 5.0 mm/mV, 10 mm/mV, 20 mm/mV Scan speed: 12.5 mm/s, 25 mm/s, 50 mm/s HR Measurement and alarm range: Adult: 15 ~ 300 bpm Pediatric/neonate: 15 ~ 350 bpm Accuracy: ± 1 % or ± 1 bpm, whichever is greater Resolution: 1 bpm ▲RESP Method: R-F (RA-LL) impedance Respiration rate: Measurement and alarm range: 0 ~ 150 rpm Resolution: 1 rpm Accuracy: 7 rpm ~ 150 rpm, ± 2 rpm or ± 2 %, whichever is greater; 0 rpm ~ 6 rpm, unspecified Apnea alarm: 10 ~ 40 s Scan speed: 12.5 mm/s, 25 mm/s ▲NIBP Measurement mode: Oscillometry Working mode: Manual / AUTO / STAT Measurement interval in AUTO mode: 1 / 2 /3 / 4 / 5/ 10 / 15 / 30 / 60 / 90 / 120 / 180 / 240 / 480 minutes Measurement period in STAT mode: 5 minutes Measurement and alarm range: 0 ~ 300 mmHg Resolution: 1 mmHg Cuff pressure accuracy: ± 3 mmHg Measurement accuracy: Maximal mean deviation: ± 5 mmHg Maximal standard deviation: 8 mmHg Over-pressure protection: Adult: 297±3 mmHg Pediatric: 260±3 mmHg Neonate: 147±3 mmHg ▲SpO2 Measurement and alarm range: 0 ~ 100% Resolution: 1 % Accuracy: 70 % ~ 100 %: ± 2 %; 0 % ~ 69 %: unspecified ▲PR Measurement and alarm range: 25 ~ 250 bpm Accuracy: ± 2 bpm or ± 2 %, whichever is greater ▲TEMP Measurement and alarm range: 0 ~ 50 ℃ Resolution: 0.1 ℃ Accuracy: ± 0.1 ℃ ▲CO2(optional) Measurement mode: mainstream or sidestream Measurement range: 0 ~ 150 mmHg Resolution: 0.1 mmHg: 0 ~ 69 mmHg 0.25 mmHg: 70 ~ 150 mmHg Accuracy: 0 ~ 40 mmHg: ±2 mmHg 41 ~ 70 mmHg: ±5 % 71 ~ 100 mmHg: ±8 % 101 ~ 150 mmHg: ±10 % AwRR measurement range: Sidestream: 2 ~ 120 rpm Mainstream: 2 ~ 150 rpm Accuracy: ±1 rpm Apnea alarm: yes ▲Power supply: 100 V-240 V ～ 50 Hz/60 Hz ▲Safety class: Class II

Product specifications
